Cartonplast Technical test

Cartonplast Sheets comparative test: (testing parameters)

These tests have been carried out in the temperature of 72 Fahrenheit degree.

The testing samples are the 4mm standards (150 Lbs) for corrugated poly propylene and corrugated cartons in the condition of  C floate and 250 Lbs.

No additive has been applied on these samples such as the flash retardants or UV protective.

Cartonplast

Technical test

No additive has been applied on these samples such as the flash retardants or UV protective.

Paper Corrugate Cartonplast Properties
0.15lb2.ft. 0.15lb2.ft. Weight for Test
76% 0.021% Water Absorption in 24 hrs
6lb2.ft. 46lb2.ft. Edge Crush Test
4lb2.in 81lb2.in Flat Crush Test
10gms. 1700gms. Tear Strength
200lb2.in 4,000 lb2.in Tensile Strength
32 in/lb 320 in/Ib Impact Dart Test
Not Applicable sq.Inch 174 °C Heat Det .Load @66Ibs.PerSq.Inch
1,000 cycles 21,000 cycles Living Hinge

The test result indicates that Cartonplast are preferable in comparison with cartons or corrugated papers as the mater of the below parameters:

  • Resistance against water and humidity
  • Reusability
  • Durability
  • Chemical resistance
  • Light weight
  • Resistance to decay and crush
  • Resistance to the temperature
